I coupled an MVD 5.6 application with a BI tool, which is Qlikview 11 Personal Edition (freeware - link below), according to the video in the link below. Video capture was slow because everything was played on a MicroSD card.
link vídeo = https://youtu.be/PJEo3ch3Dic
I obtained the script below here on the forum, which exports data from the MVD application to a file in CSV format.
I created a dashboard in Qlikview from the CSV file. Below is the script I used in the dashboard, which loads data from the CSV file, which is used to create tables, graphs, etc. in Qlikview,
Qliview's capabilities and possibilities are far above this small example. There are countless tutorials, including videos, on the internet. In addition to the help file (CHM) and the examples that accompany it.
Limitations of the Personal Edition version (taken from the internet): "QlikView Personal Edition is a free version of QlikView for personal use. It is the full QlikView Desktop product and uses the same installation package1. However, there are some limitations and aspects to be observed:
QlikView Documents: In QlikView Personal Edition, every document is saved with a user key that associates the file with the computer on which it was created1. This means that you cannot use your QlikView documents on other computers, share your QlikView documents with another unregistered user, and cannot open another user's QlikView document1. However, documents created in QlikView Personal Edition can be used with a licensed copy of QlikView Desktop and can also be published to a QlikView Server1.
File recovery: If you change computers, you will not be able to open documents previously created with QlikView Personal Edition1. In this case, you can choose to recover your files1. QlikView will accept 4 user key changes in a document1. After this, the error message “Key length has reached maximum” will be displayed and the document will no longer open1.
Support: QlikView Personal Edition users are not eligible for phone or email support from Qlik, but can get excellent support for QlikView from our Qlik1 Community."
Qlikview download link. I downloaded it from the manufacturer's website at the time:
https://drive.google.com/file/d/1jeWUs4 … sp=sharing
SCRIPT USED IN THE MVD APPLICATION
procedure frmOverview_bExpCSV_OnClick (Sender: TObject; var Cancel: boolean);
var
filename: string;
begin
frm_aviso.Show;
Form1_bExport; //aciona rotina exportação de lancamento_all_view para arquivo CSV, que será utilizado no qlikview
filename := 'dashboard_orcamento_jrga.qvw';
OpenFile(filename);
frm_aviso.Close;
end;
procedure Form1_bExport;
var Sl : TstringList;
folder: string;
TableNames: TDataSet;
TableCols: TDataSet;
TableName,ColName,Cols,SelectStmt,ColType: string;
begin
ProgressBar := TProgressBar.Create(frmMyNotas);
ProgressBar.Parent := frmMyNotas.pnProgressBar;
ProgressBar.Width := frmMyNotas.pnProgressBar.Width;
ProgressBar.Height := frmMyNotas.pnProgressBar.Height;
ProgressBar.Position := 0;
ProgressBar.Max := 10;
Sl := TstringList.Create;
//SelectDirectory('Select Folder to Export File', './', folder, True); //Dialog to select folder for which the exported file will be created
//If Folder = '' then Exit; // If no folder is selected then cancel the export
frmMyNotas.pnProgressBar.Visible := True;
frmMyNotas.lblImpExp.Caption := 'Exporting Database';
application.processmessages;
SqlQuery('SELECT name FROM sqlite_master WHERE type="view" and name = "lancamento_all_view"',TableNames); // Retrieve all tablenames from database and load into a dataset
while not TableNames.Eof do // Run through each tablename dataset
begin
Cols := '';
SelectStmt := '';
TableName := TableNames.FieldByName('name').AsString;
SqlQuery('pragma table_info(' + TableName + ')',Tablecols); // Retrieve column (fields) names for each table
While not TableCols.Eof do // Go through each column (field) and concatenate together with comma separation
begin
ColName := TableCols.FieldByName('name').AsString;
ColType := Tablecols.FieldByName('type').AsString;
If ColType <> 'BLOB' then Cols := Cols + ColName + ','; // Do not select images for exporting
TableCols.Next;
end;
Delete(Cols, Length(Cols), 1); // Remove ending comma from column list
ProgressBar.Position := ProgressBar.Position + 10;
ExportToSl(TableName,Cols,Sl); // Run Export procedure - pass the tablename and the list of columns to the procedure
TableNames.Next; // Go to next table name in dataset
end;
Sl.SavetoFile(path_atual+'ExportedData.csv'); // Save the stringlist to a csv file into the specified folder
ProgressBar.Free;
frmMyNotas.pnProgressBar.Visible := False;
frmMyNotas.lblImpExp.Caption := '';
//ShowMessage('Dados foram exportados para CSV');
Sl.Free;
TableNames.Free;
TableCols.Free;
end;
SCRIPT USED IN QLIKVIEW. Loads data for use with Qlikview graphical objects. The first 10 lines are created automatically. Once the table with the data has been chosen, Qlikview will generate the "LOAD ...FROM" structure
SET ThousandSep='.';
SET DecimalSep=',';
SET MoneyThousandSep='.';
SET MoneyDecimalSep=',';
SET MoneyFormat='R$ #.##0,00;-R$ #.##0,00';
SET TimeFormat='hh:mm:ss';
SET DateFormat='DD/MM/YYYY';
SET TimestampFormat='DD/MM/YYYY hh:mm:ss[.fff]';
SET MonthNames='jan;fev;mar;abr;mai;jun;jul;ago;set;out;nov;dez';
SET DayNames='seg;ter;qua;qui;sex;sáb;dom';
Directory;
Lancamentos:
LOAD TableName,
data as "Data",
tipo_conta as "Iipo Conta",
conta as "Conta",
categoria as "Categoria",
subcategoria as "Subcategoria",
categoria &' : '& subcategoria as "Categ.e subcat.",
cheque as "Nºcheque",
grupo as "Grupo fornecedor",
fornecedor as "Fornecedor",
if(id_tipo_operacao='1','Entrada','Saída') as "Tipo operação",
Replace(entrada,'.',',') as "Vlr entrada",
Replace(saida,'.',',')*-1 as "Vlr saida",
(Replace(entrada,'.',',') + Replace(saida,'.',',')*-1) as "Valor",
Replace(meta_anual,'.',',') as "Meta anual",
notas as "Notas",
id_lancamento as "ID lancamento",
id_tipo_conta as "ID tipo conta",
id_conta as "ID conta",
id_categoria as "ID categoria",
id_tipo_operacao,
id_subcategoria as "ID subcategoria",
id_grupo as "ID grupo",
id_fornecedor as "ID fornecedor",
checado as "Conciliado"
FROM
ExportedData.csv
(txt, utf8, embedded labels, delimiter is ',', msq)
WHERE len(categoria) <>0;
LOAD data as "Data"
, year([data]) as Ano
, month([data]) as Mes
, day([data]) as Dia
FROM
ExportedData.csv
(txt, utf8, embedded labels, delimiter is ',', msq);
P.S.: in the document settings, in Qlikview, it is possible to create a trigger, which updates the dashboard data, as soon as the QVW file is opened.
